PV Branch Connectors

Alpha Products, Inc. 351 Irving Drive, Oxnard, CA 83030, USA
Tel: 805-981-8666 / Fax: 805-988-6555 /
Contact Us

Fig.

Part Number

Rated Current

Description

3SO/BCO1

20A

 2 male + 1 female, self-locked, 2.4mm dia.

3SO/BCO2

20A

1 male + 2 male, self-locked, 2.4mm dia.

3SO/BCO27

20A

2 male + 1 female, self-locked, 4.0mm dia.

3SO/BCO26

20A

2 female + 1 male, self-locked, 4.0mm dia.

Specifications

Current rating

 20A max

Rated voltage

 600V

Contact resistance

 5 mOhm max

Protection class

 II

Housing material

 PPO

Terminal material

 Copper, tin plated

Protection degree

 IP67

Flame class

 UL94V-0

Temperature range

 -400C to +850C
